Payments as low as $203.27 per month

ENGINE OPTIONS

Kawasaki

• 999cc, 38.5 HP FX1000V EFI (61"/72")

Vanguard

• 993cc, 37 HP EFI (61"/72")

• 993cc, 40 HP EFI V-Twin (61"/72")

DECK & CONSTRUCTION

• Deck Sizes: 61" & 72"

• Deck Thickness: 1/4" (3-gauge) welded steel

• Reinforced Deck Sides: 3/8"

• Sloped deck design for optimal airflow & cut quality

• Frame: Heavy-gauge, all-steel, all-welded

• Patented Dual Deck Support Isolators

• PEER Maintenance-Free Cast Spindles

DRIVE SYSTEM

• Hydro-Gear 5400 Series integrated transaxles

• High-torque 16cc pump equivalent

• Ground Speed: Up to 12 MPH

MICHELIN® X® TWEEL® TIRES

• Rear Tires: 24×12–12 Michelin X Tweel Turf tires

• Front Tires: 13×6.5–6 smooth no-flat casters

Benefits:

• No flats

• Larger contact patch

• Superior hillside stability

• Smoother ride at speed

• Even ground pressure for improved turf protection

DIMENSIONS

• Cutting Widths: 61" / 72"

• Length: 92"

• Width (Chute Up / Down):

  • 61": 63.5" / 75.5"

  • 72": 74.5" / 86.5"

• Height (ROPS Down / Up): 50" / 75.6"

• Weight:

  • 61": 1,494 lbs

  • 72": 1,531 lbs

CUTTING SYSTEM

• Cutting Height: 1"–5"

• Lift Adjustment: Foot-assist manual lift + dial height control

FUEL & PERFORMANCE

• Fuel Capacity: 13 gallons (unleaded gasoline)

• Engine HP Range: 37–40 HP

• Deck Sizes: 61", 72"

• Ground Speed: Up to 12 MPH
